Product Description
Enjoy precise temperature control with the Nepra™ 4000 from PSG Controls, a 24 volt heating and cooling digital thermostat designed for use with packaged terminal heat pumps and air conditioners. This versatile thermostat can also be configured for use on 4-pipe or 2-pipe units with electric heat fan coil systems.
Psg Nepra 4000 Series Manual Transmission
Featuring low, medium and high fan cycle speeds as well as calls for heating and cooling, this thermostat provides digital set point display, configurable limits and automatic heat/cool changeover. The control can be placed in economy mode or off mode with 40° freeze protection.
Quick Specs
- Input Voltage: 24 VAC
- Load Rating: 1.5 amps per circuit
- Temperature Monitor Range: 60°F to 85°F32.0°F to 99.9°F (0.0°C to 37.7°C)
- 3.5”W x 5.0”H x 1.5”D
Psg Nepra 4000 Series Manual User
Specifications
| Weight | 1 lbs |
|---|---|
| Dimensions | 6 × 6 × 6 in |
| Input Voltage | 24 VAC |
| Load Rating | 1.5 amps per circuit |
| Temperature Monitor Range | 60°F to 85°F32.0°F to 99.9°F (0.0°C to 37.7°C) |
| Economy Limits | Maintains room temperature between 60.0°F and 85.0°F (15.5°C and 29.5°C) when thermostat is in economy mode |
| Accuracy | ±1°F |
| Cycle Rate | 6 cycles per hour |
| Case Material | Flame retardant, high impact plastic, white |
| Dimensions | 3.5”W x 5.0”H x 1.5”D |
| Setpoint Range | 60.0°F to 85.0°F (15.5°C to 29.5°C) |
| Setpoint | 72.0°F (22.0°C) |
| Comfort Limits | 65.0°F (18.5°C) cooling 85.0°F (29.5°C) heating |
| Display Format | Liquid Crystal Display (LCD) |
| Sampling Rate | Every 5 seconds |
| Fan Control | Selectable: Auto cycle, Low, High, Economy, Off |
| Heat/Cool Control | 1 Compressor, 1 Auxiliary Heat |
| Fan Purge Timer | 30 seconds |
| Anti-Short Cycle | 3 minute hold in no call state at all times |
